Roborock E4 Robot Vacuum and Mop Cleaner Instruction Manual

1. Εισαγωγή

The Roborock E4 is a versatile robot vacuum and mop cleaner designed to efficiently clean various floor types in your home. It features powerful suction, intelligent navigation, and a long-lasting battery, making it suitable for daily cleaning and managing pet hair.

Figure 1: Roborock E4 Robot Vacuum and Mop Cleaner

This manual provides detailed instructions for setting up, operating, and maintaining your Roborock E4 to ensure optimal performance and longevity.

2. Ρύθμιση

2.1 Αποσυσκευασία και Έλεγχος Εξαρτημάτων

Carefully remove all components from the packaging. Ensure all items listed in the 'Included Components' section of the specifications are present.

2.2 Τοποθέτηση βάσης φόρτισης

Place the charging dock against a wall on a hard, level surface. Ensure there is at least 0.5 meters (1.6 feet) of clear space on both sides and 1.5 meters (4.9 feet) in front of the dock. Connect the power cable to the dock and plug it into a power outlet.

2.3 Αρχική φόρτιση

Place the Roborock E4 onto the charging dock. The robot will automatically align and begin charging. For first-time use, allow the robot to charge completely before its initial cleaning cycle. The power indicator light will change to solid white when fully charged.

2.4 Σύνδεση με την εφαρμογή Roborock

1. Download the Roborock app from your mobile device's app store.
2. Ανοίξτε την εφαρμογή και ακολουθήστε τις οδηγίες που εμφανίζονται στην οθόνη για να δημιουργήσετε έναν λογαριασμό.
3. Select 'Add Device' and choose your Roborock E4 model.
4. Follow the in-app prompts to connect your robot to your home Wi-Fi network.

3. Λειτουργία

3.1 Έναρξη και διακοπή καθαρισμού

To start a cleaning cycle, press the Power button on the robot or use the Roborock app. To pause cleaning, press the Power button again. To send the robot back to the charging dock, press the Home button on the robot or use the app.

3.2 Λειτουργία ηλεκτρικής σκούπας

The Roborock E4 utilizes 2000Pa strong suction to effectively pick up dirt, dust, and pet hair from various surfaces including wood, tiles, and carpets. It employs OpticEye, dual gyroscopes, and precision internal mapping for a methodical Z-shape cleaning pattern.

3.3 Mopping Mode

The E4 features a 2-in-1 vacuum and mop function. To activate mopping:

1. Γεμίστε τη δεξαμενή νερού με καθαρό νερό.
2. Προσαρμόστε το πανί σφουγγαρίστρας στο δοχείο νερού.
3. Slide the water tank assembly into the back of the robot until it clicks into place.
4. Adjust the water flow level via the Roborock app (High or Low) based on your floor type and cleaning needs.

The robot will vacuum and mop simultaneously, removing fine dust that vacuuming alone might miss.

3.4 Carpet Boost

The Roborock E4 automatically detects carpets and increases suction power for deeper cleaning. This feature ensures thorough cleaning across different floor types without manual intervention.

3.5 App Control and Voice Assistant

The Roborock app provides total control over your E4. You can:

• Start, pause, or stop cleaning.
• Προγραμματίστε ώρες καθαρισμού.
• Ρυθμίστε την ισχύ αναρρόφησης και τα επίπεδα ροής νερού.
• View καθαρισμός χαρτών και ιστορικού.
• Receive maintenance alerts.

The E4 also supports voice control through compatible devices like Amazon Echo, allowing for hands-free operation.

Video 1: Official Roborock E4 Mop Robot Vacuum Cleaner overview, demonstrating its features and operation.

4. Συντήρηση

Regular maintenance ensures your Roborock E4 operates efficiently and extends its lifespan. Refer to the app for specific maintenance schedules.

4.1 Άδειασμα του κάδου απορριμμάτων

The E4 features a large 640ml dustbin. It should be emptied after each cleaning cycle or when full. To empty, lift the top cover of the robot, unclip and remove the dustbin, and discard the contents.

4.2 Καθαρισμός και αντικατάσταση του φίλτρου

The E11 rated filter is washable. It is recommended to wash the filter every two weeks and replace it every 150 hours of use. After washing, allow the filter to air dry completely before reinserting.

4.3 Βούρτσες καθαρισμού

• Πλαϊνή βούρτσα: Check and clean the side brush regularly. Replace after 200 hours of use.
• Κύρια βούρτσα: Remove any tangled hair or debris from the main brush. Replace after 300 hours of use.

4.4 Καθαρισμός αισθητήρων

Clean the various sensors (infrared, cliff-sensors) every 30 hours of use with a soft, dry cloth to ensure proper navigation and prevent falls.

4.5 Καθαρισμός δεξαμενής νερού και σφουγγαρίστρας

After each mopping session, empty any remaining water from the tank and clean the mop pad. The mop pad is reusable and can be hand-washed or machine-washed.

Εικόνα 2: Κάτω πλευρά view of the Roborock E4, highlighting the main brush, side brush, and mop pad attachment area.

5. Αντιμετώπιση Προβλημάτων

If you encounter issues with your Roborock E4, refer to the following common solutions:

• Το ρομπότ δεν φορτίζει: Βεβαιωθείτε ότι η βάση φόρτισης είναι ενεργοποιημένη και ότι το ρομπότ είναι σωστά ευθυγραμμισμένο με τις επαφές φόρτισης. Καθαρίστε τις επαφές φόρτισης τόσο στο ρομπότ όσο και στη βάση.
• Το ρομπότ κολλάει: Clear obstacles like loose cables, small objects, or thick rugs from the cleaning path. The robot is designed to climb over 0.8-inch (2cm) obstacles, but higher thresholds may cause issues.
• Κακή απόδοση καθαρισμού: Empty the dustbin, clean or replace the filter, and remove any tangled hair from the main and side brushes. Check if the water tank is filled for mopping.
• Προβλήματα συνδεσιμότητας εφαρμογών: Ensure your robot is within Wi-Fi range and your Wi-Fi network is stable. Restart your router and the robot.
• Robot not returning to dock: Ensure the charging dock is accessible and not blocked by furniture or other items.

For persistent issues, consult the Roborock app for further diagnostics or contact customer support.

6. Προδιαγραφές

7. Εγγύηση & Υποστήριξη

Για πληροφορίες εγγύησης και υποστήριξη πελατών, ανατρέξτε στην επίσημη Roborock webστον ιστότοπο ή επικοινωνήστε απευθείας με την εξυπηρέτηση πελατών. Κρατήστε την απόδειξη αγοράς σας ως απόδειξη αγοράς για αξιώσεις εγγύησης.
